Philco PT-25--BIG MESS - vecher - 02-19-2019

Philco PT-25 Code 122.. Need as much info as I can get.. Especially the layout of the bottom of the radio..

Cannot find the link for Chuck to order schematic and info..  Maybe someone has that info and would share..

Thanks
Skip

RE: Philco PT-25 Code 122 - Arran - 02-20-2019

Skip;
  I think what you are looking for may be here:

http://philcoradio.com/library/index.php/service-info/philco-1940-rms-year-book/

Regards
Arran

RE: Philco PT-25 Code 122 - Ron Ramirez - 02-20-2019

...and the link you want for Chuck's schematic service is here:

https://www.philcorepairbench.com/schematics/

RE: Philco PT-25 Code 122 - vecher - 02-20-2019

Ron and Arran, Ok thanks.. I found the link to Chuck But haven't heard back from him yet?

Looks like my PT-25 has been monkey with.. Bottom looks pretty messed up.. Thats why I need to see what the bottom is supposed to look like..

Here is bottom..

[Image: https://farm8.staticflickr.com/7845/47107460872_16cbefc596_b.jpg]

I guess I should start a post in right area..

Skip

RE: Philco PT-25 Code 122 - Ron Ramirez - 02-20-2019

Skip, I'll move it to Philco Electronic Restoration for you.

Edit: Done.

RE: Philco PT-25 Code 122 - vecher - 02-21-2019

Have not been able to get hold of Chuck Yet.. Does anyone know if he is still around??

Still looking for a parts layout of bottom of chassis..

Skip

RE: Philco PT-25 Code 122 - Ron Ramirez - 02-21-2019

Yes he is still around as far as I know; someone here just recently ordered, and received, a schematic packet from him.

He's retired now and enjoying it, so he may take longer to answer you.

RE: Philco PT-25 Code 122 - vecher - 02-21-2019

Ron, Ok thanks I will wait until I hear from him..

Skip

RE: Philco PT-25 Code 122 - vecher - 02-22-2019

OK after removing the Electrolytic Replacement Cap I found this....

[Image: https://farm8.staticflickr.com/7849/47180597411_a14cc982d0_z.jpg]


[Image: https://farm8.staticflickr.com/7864/47180597561_a0713c2e02_z.jpg]

Looks like the Original cap exploded.. also finding a lot of crumbled wire.. And replacement wire.. See the YEL/Blk wire throughout..
..

This is going to be a real issue..

Skip

RE: Philco PT-25 Code 122 - David - 02-22-2019


Beitmans

RE: Philco PT-25 Code 122 - vecher - 02-26-2019

Ok, Looks like all of the wiring needs to be replaced along with the IF can..

[Image: https://farm8.staticflickr.com/7917/33347137868_6dd909628a_b.jpg]

[Image: https://farm8.staticflickr.com/7916/33347137388_5bb324b79d_b.jpg]

[Image: https://farm8.staticflickr.com/7874/33347137168_f417c313a3_b.jpg]

[Image: https://farm8.staticflickr.com/7864/47180597561_a0713c2e02_z.jpg]


[Image: https://farm8.staticflickr.com/7917/33347137598_d3b2a13ce7_b.jpg]


What a PIA..

Skip

RE: Philco PT-25 Code 122 - Arran - 02-27-2019

Skip;
  Is the IF can actually open circuit or just another victim of crumbling insulation?
Regards
Arran

RE: Philco PT-25 Code 122 - vecher - 02-27-2019

IF can is OK.. Just replacing wires..

Skip

RE: Philco PT-25 Code 122 - vecher - 02-28-2019

Well, Just got a package from Chuck.. Very disappointing 4 sheets that I already have.. NO bottom layout..

Total waste of 7.00 Maybe that's all chuck had.. But Doesn't help me .. Just venting...

I have received packets from Chuck that were excellent..

PS still need a layout of the bottom of this thing...

Skip

RE: Philco PT-25 Code 122 - Ron Ramirez - 02-28-2019

It's probably all that is available. Don't blame Chuck.

Unfortunately Philco did not provide much in the way of service info for many of the PT series of radios. For some of those, you're lucky if you can get a schematic and maybe a parts list.
