46-1226 code 125 restoratioin *DONE

jcassity
Senior Member

Posts: 648
Threads: 50
Joined: Mar 2017
City: Gap Mills Wv 24941

#129

05-01-2017, 10:27 PM

voltage reading results
again, R102 is the one getting very hot

Part      AC across      AC IN     AC Out      DC across    DC in     DC Out    OHMS     Comment
R100     O                 0            0              0                0           0            271        could be intermittant / candohm
R103     4.6               4,5         1.2           50             226        175        1341
R101     4.5               4.7         1.4           63              226        162        10024
R102     65.5             66.9       4.8            74             301         226        511         substituting/300ohm call out
v6-3 -- 4.3 -- -- 214 -- -- 6k6, from chassis to pin 3
v7-3 -- 5 -- -- 212 -- -- 6k6, from chassis to pin 3
Green    --                 0            --              --              0            --           --            T6/T100 green highV center tap
