Philco Radio Tube Analyzer
Posts: 1
I have an old tube tester and was trying to find some information on it.
It is a -
Philco Radio Tube Analyzer Radiotechnic Laboratory Evanston, Illinois - Model R Series B .
I was surprised to find the only photo or information I could find on the internet that was close to the one I have is on this link,
https://www.invaluable.com/auction-lot/1...b948999c6#
but this picture is only the very top of the tube tester. (It looks like the top is all that was left of this one and someone mounted it on a board and sold it.)
I don't know if anyone would be interested in it, or would have the time to point me the right direction to find someone else who might be. I would appreciate it.
Thank you.
Dave
Posts: 7,286
You might try giving Steve Johnson a note:
https://stevenjohnson.com/testers-misc.htm
He has a lot of info on old test equipment.
GL
Posts: 16
Hi Dave. Did you ever find out more about your tube tester? I found one of my own and information on it seems pretty scarce.
Posts: 2,026
Almost looks like something out of an old Penny Arcade. Neat!
Posts: 1,598
Hello Dave,
Posts: 1,824
Neat old tester. Now, to find the settings chart to go with it ! Someone must have one somewhere. Folks, if you have one, let these guys know ! Or, ask on Antique Radio Forum
Posts: 76
10-19-2023, 08:50 AM
Hey Folks - I just acquired the portable version of this. If I am lucky enough to find more info on this, I will post it here. -- Andy
Attached Files
Image(s)
Posts: 161
Although I have manuals and service information for a fair amount of Philco test equipment that appears to predate everything for which I have information.
Dale H. Cook, GR/HP/Tek Collector, Roanoke/Lynchburg, VA
https://plymouthcolony.net/starcity/radios/
Posts: 1
Attached Files
Image(s)
Posts: 1,975
Post by Chris T was a duplicate and deleted. Gary
